死端系统：触发喷洒装置并观察是否有吐痰
当空气被净化时。喷洒模式连续时停止，并且
即使
循环系统：关闭循环阀（10），打开
排放阀（11）。观察排放杆的流量。当没有更多
发现气泡，关闭排放阀并缓慢打开
循环阀，直到泵以所需数量运行
每分钟周期数。触发喷洒装置以清除空气
他们
注：循环阀打开越多，潜力越大
当
泵改变方向或移动。打开循环阀
足以在
循环回路。
确保空气润滑器每17滴输送一滴−25冲程。
根据需要调整交付率。
打开液体加热器（9）（如果使用），并在
加热器出口。通过加热器循环涂层材料，直到达到
喷涂零件前的所需温度。
注意：过热的涂层材料可能会导致泵内产生气穴
如果涂层材料中的溶剂在真空中蒸发
虹吸循环期间。如果发生这种情况，请降低加热器恒温器
背景有关更多信息，请参阅第B5节，故障诊断与排除。
3. Purge air from the system:Dead-end system: Trigger the spray devices and watch for spitting
as air is purged. Stop when the spray pattern is continuous and
even.
Circulating system: Close the circulation valve (10) and open the
drain valve (11). Watch the flow from the drain rod. When no more
air bubbles are seen, shut the drain valve and slowly open the
circulation valve until the pump is running at the desired number of
cycles per minute. Trigger the spray device(s) to purge air from
them.
NOTE: The more the circulation valve is opened, the more potential
there is for fan pattern collapse or “wink” at the spray device when the
pump changes direction or shifts. Open the circulation valve just
enough to maintain the required fluid temperature and agitation in the
circulation loop.
4. Make sure the air lubricator is delivering one drop every 17−25 strokes.
Adjust the delivery rate as needed.
5. Turn on the fluid heaters (9), if used, and watch the thermometer at the
heater outlet. Circulate coating material through the heater until it is at
desired temperature before spraying parts.
NOTE: Overheating coating materials can cause cavitation in the pump
if the solvents in the coating material boil out in the vacuum created
during the siphon cycle. If this happens, lower the heater thermostat
setting. Refer to Section B5, Troubleshooting for more information.
