72395-4-0399123模块备件参数说明

今天有个朋友发信息问我，说他们单位有一排6盏路灯，这6盏灯同时开，同时关，每盏路灯1000瓦，他想用一台时控开关控制这6盏灯，问我怎么接线。我说一台时控开关只能控制10安电流的负载，你这6盏灯加起来6000瓦，电流太大，必须加接触器。他又问我怎么加接触器，具体怎么接线？那么咱们就根据这个实例讲解一下时控开关配合接触器接线方法，希望可以帮到有同样疑问的初学者。首先来选择一台接触器，6盏灯6000瓦，算出它的总电流。
Today, a friend sent a message to me, saying that there are six street lights in their unit. The six lights are on and off at the same time, and each street light is 1000 watts. He wants to use a time-controlled switch to control the six lights, and asked me how to connect the wires. I said that a time control switch can only control the load with a current of 10 A. your six lights add up to 6000 watts. The current is too large, so you must add a contactor. He asked me how to add contactors and how to connect them specifically? Then let's explain the wiring method of time control switch and contactor according to this example, hoping to help beginners with the same questions. First of all, choose a contactor, 6 lamps, 6000 watts, and calculate its total current.
