PLC控制柜的生产是一个严格而繁琐的过程，因为它在系统控制中起着很大的作用，不能容忍任何粗心大意。在生产过程中，亚业智能经过了严格的程序测试。选材合理，使用寿命长，可靠。它还可以支持定制以满足需求。让我们看一下PLC控制柜的生产过程？
PLC控制柜生产工艺：
1.PLC控制柜前后门采用2.0mm厚冷轧钢板，两侧采用1.5mm厚冷轧钢板。
2、PLC控制柜前门、后门均设计有玻璃门（玻璃门应观察PLC及柜门上主要设备的状况，保证柜门整体外观，多个控制柜门应一致），并打开后双门。
3、机柜下端至箱体底部100mm处设盖板。盖板分为正面和背面。每个盖板两侧凹槽左侧附近应有200mm×100mm的排放孔。
4、设备部件应安装在控制柜的前后布置中，即双面立梁布置，前后立梁之间的纵梁前部在100mm至300mm之间，前门，后立梁和后门在400mm之间。
5、排风机安装在PLC控制柜顶部中央。机柜顶部安装在know light前后，计量机柜顶部安装在know light之后。
6、机柜两侧靠近机柜侧板的垂直线槽应靠近机柜侧板，以确保机柜内的有效净空间。
7、PLC柜内s7-300/400底板安装在绝缘胶合板上，底板与柜体绝缘。
8、PLC柜内组件及其他组件（随机柜布置）应符合安装图纸。
9、柜内接线按图纸设计。柜内接线端子应短路
The production of PLC control cabinet is a strict and cumbersome process, because it plays a great role in system control, and any carelessness cannot be tolerated. In the production process, Yaye intelligence has undergone strict program testing. Reasonable material selection, long service life and reliability. It can also support customization to meet requirements. Let's have a look at the production process of PLC control cabinet?
Production process of PLC control cabinet:
1. The front and rear doors of PLC control cabinet are made of 2.0mm thick cold-rolled steel plates, and both sides are made of 1.5mm thick cold-rolled steel plates.
2. The front and rear doors of the PLC control cabinet are designed with glass doors (the glass doors should observe the conditions of the PLC and the main equipment on the cabinet doors to ensure the overall appearance of the cabinet doors, and multiple control cabinet doors should be consistent), and open the rear double doors.
3. A cover plate is set at 100mm from the lower end of the cabinet to the bottom of the box. The cover plate is divided into front and back. There shall be 200mm near the left side of the groove on both sides of each cover plate × 100mm drain hole.
4. The equipment components shall be installed in the front and rear layout of the control cabinet, that is, the double-sided vertical beam layout. The front of the longitudinal beam between the front and rear vertical beams is between 100mm and 300mm, and the front door, rear vertical beam and rear door are between 400mm.
5. The exhaust fan is installed in the center of the top of the PLC control cabinet. The top of the cabinet is installed before and after the know light, and the top of the metering cabinet is installed after the know light.
6. The vertical trunking on both sides of the cabinet close to the cabinet side plate should be close to the cabinet side plate to ensure effective net space in the cabinet.
7. The s7-300/400 bottom plate in the PLC cabinet is installed on the insulating plywood, and the bottom plate is insulated from the cabinet.
8. The components in the PLC cabinet and other components (random cabinet layout) shall comply with the installation drawings.
9. The wiring in the cabinet is designed according to the drawing. The wiring terminal in the cabinet shall be short circuited
