压缩空气向下推动活塞（6）和柱塞（10）。空气低于
活塞通过下气缸盖（9）、连接管（8）排气
阀门（2）和消音器（4）。压力球形止回阀（14）打开
虹吸球形止回阀（15）关闭。涂层材料位于
液压部分加压并从泵中压出。
当活塞到达行程底部时，换档机构（1）
将空气阀滑阀（3）移到阀的另一侧。吸入口
笔划再次开始。
死端和循环系统运行
在终端系统中，泵在施加气压时启动。信息技术
继续操作，直到系统中的液压等于
利用可用的空气压力，泵可以产生的压力。泵
然后暂停，直到液体压力下降，例如当喷枪
已触发。
在循环系统中，泵以
循环阀。打开阀门使泵运行更快；
关闭阀门会减慢泵的速度。正常工作速率为8到10
每分钟冲程数。
柱塞润滑
溶剂室包含润滑液（溶剂室液），其
润滑柱塞上部，防止上部填料
过度磨损。泵送的涂层材料润滑
下部填料。
注：通过上填料压盖泄漏的涂层材料将变色
溶剂室中的液体并使其液位升高。少量的
泄漏正常。如果溶剂杯快速填充并溢出填料
需要更换。应在以下位置更换上填料和下填料
同样的时间。
