填料。这些适用于大多数一般的面漆材料
和溶剂。
可选填料可用于其他涂层材料和
溶剂。参考填料压盖材料指南和填料压盖
第A-1节“快速参考”中的选择图表，用于选择和排序
为涂层材料校正填料压盖。
有关更多信息，请联系Nordson Finishing客户支持
中心或您当地的Nordson代表。
泵操作
见图B 2-1。
64B泵为按需式双作用泵。A需求类型
当系统中的液压降至压力以下时，泵启动
泵可以利用可用的空气压力进行生产。泵停止运行
当流体压力等于泵可以产生的压力时
可用空气压力。双作用泵加压和泵
吸入冲程和压力冲程上的涂层材料。
这些泵由空气马达（17）和液压部分（16）组成。空气
电机驱动泵。换档机构（1）和空气阀（2）控制
空气活塞（6）、连杆（7）和液压的方向
柱塞（10）。上下填料（12和13）防止涂层
材料通过柱塞泄漏。虹吸球止回阀（15）和
压力球形止回阀（14）控制流经液压系统的液体流量
部分
Standard pumps are shipped with Type-F (PTFE/leather) hydraulic packings. These are suitable for most general finishing coating materials and solvents. Optional packings are available for use with other coating materials and solvents. Refer to the Packing Gland Material Guide and Packing Gland Selection Chart in Section A-1, Quick Reference, to select and order the correct packing glands for your coating material. For more information, contact the Nordson Finishing Customer Support Center or your local Nordson representative. Pump Operation See Figure B 2-1. The 64B pumps are demand-type, double acting pumps. A demand-type pump starts when the fluid pressure in the system falls below the pressure the pump can produce with the available air pressure. The pump stops when the fluid pressure equals the pressure the pump can produce with the available air pressure. A double-acting pump pressurizes and pumps coating material on both the suction stroke and the pressure stroke. The pumps consist of an air motor (17) and hydraulic section (16). The air motor powers the pump. The shifter mechanism (1) and air valve (2) control the direction of the air piston (6), connecting rod (7), and hydraulic plunger (10). The upper and lower packings (12 and 13) prevent coating material from leaking past the plunger. The siphon ball check (15) and pressure ball check (14) valves control the flow of fluid through the hydraulic section.
