1746-N2模块备件实验数据

•验证Logix5550控制器和1756-CNB模块是否处于工作状态
每个ControlLogix机箱中的插槽0和1，如图所示。
•验证1756-CNB模块的节点地址是否为1和6
展示。
•验证KTCX15驱动程序卡的配置是否如中所述
第2-3页。
•验证所有接线和布线是否正确连接。
创建制作人
应用
执行以下步骤以创建producer应用程序。
1.打开RSLogix5000软件。
2.从“文件”菜单中，选择“新建”。新的控制器窗口将
显得• Verify that the Logix5550 controllers and the 1756-CNB modules are in slots 0 and 1 in each ControlLogix chassis, as shown. • Verify that the node addresses for the 1756-CNB modules are 1 and 6 as shown. • Verify that the KTCX15 driver card is configured as described on page 2-3. • Verify that all wiring and cabling is properly connected. Create the Producer Application Perform the following steps to create the producer application. 1. Open the RSLogix5000 software. 2. From the File menu, select New. The New Controller window will appear.
