•控制定时器：16位，4 CAPCOM
通道，3个互补输出，死区时间
插入和灵活的同步
•16位通用定时器，带3个CAPCOM
通道（IC、OC或PWM）
•带8位预分频器的8位基本定时器
•自动唤醒计时器
•窗口和独立看门狗定时器
通信接口
•带时钟输出的UART，用于同步
操作、智能卡、IrDA、LIN主模式
•高达8 Mbit/s的SPI接口
•我
高达400 Kbit/s的2C接口
模数转换器（ADC）
•10位ADC，±1 LSB ADC，多5
多路复用信道、扫描模式和模拟
监察人
I/O
•32针封装上多28个I/O，包括21个
高水槽输出
•高度稳健的I/O设计，不受
电流注入
发展支持
•嵌入式单线接口模块
（SWIM）用于快速芯片编程和非侵入式调试
•6个向量上多27个外部中断
Timers • Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs, dead-time insertion and flexible synchronization • 16-bit general purpose timer, with 3 CAPCOM channels (IC, OC or PWM) • 8-bit basic timer with 8-bit prescaler • Auto wakeup timer • Window and independent watchdog timers Communications interfaces • UART with clock output for synchronous operation, SmartCard, IrDA, LIN master mode • SPI interface up to 8 Mbit/s • I 2C interface up to 400 Kbit/s Analog to digital converter (ADC) • 10-bit ADC, ± 1 LSB ADC with up to 5 multiplexed channels, scan mode and analog watchdog I/Os • Up to 28 I/Os on a 32-pin package including 21 high-sink outputs • Highly robust I/O design, immune against current injection Development support • Embedded single-wire interface module (SWIM) for fast on-chip programming and nonintrusive debugging
